298#

Apply to automotive interior, health-care furnishing, commercial projects

Browse By Category

Specification

f5b81d4103e0b8954ef3bfea0c55870afe4677c0171aef-fXQYvK_fw1200(1)

BASIC INFO.
PROJECT	UNIT	STANDARD	RESULT
Thickness	mm		1.0±0.05
Width	cm		≥137
Weight	gram/m2	DIN 2286	550±20
Composition	Top Layer: PC, Middle layer: PU; Backing: 100% PES

PHYSICAL PROPERTY
Abrasion Resistance	cycle	Mardidale Test	300,000
	cycle	Wyzenbeek Test	200,000
	cycle	Taber Test	5,000
Scratch Resistant	4.12 in Q/BYDQ-A1901.402.3		No Pierce and Tearing
Tear Strength	N	ISO 4674	Warp 35; Weft 36
Tensile Strength	N	ISO 1421	Warp 730; Weft 430
Elongation Rate	%	ISO 4674	Warp 123; Weft 190
Color Fastness to Rubbing	Grade	ISO 105 X12	Wet 4.5 ; Dry 4.5

PHYSICAL PROPERTY
Color fastness to light	Grade	ISO 105 B02	Blue Scale ≥6;
UV resitance	Hours	ISO4892-2	800
Flex Resistance	times	ISO 5402	>200,000
Hydrolysis Resistance	Week	ISO 1419 Method C	15
75% Alcohol resistant ; 84 disinfectant;isopropanol	Grade	ISO105 X12	4
Flame Resistance	BS5852 0,1/ CA117/ FMVSS302 / IMO.A652.(16)8.2 / DIN 1021 1,2/GB 8410/ ASTM 84/ DIN 4102 B2/EN71-2
Chemical resitance	Soap water, multifunitional foam cleaner,household detergent,orange juice, tea ,cola, ethanol,sweat, suncreen,hand cream,ink,shoe oil
Voc Test	Benzene≤0.01; Toluene<0.05; Ethylbenzene0.1; Xylene<0.1, Styrene<0.02; Formaldehyde<0.03, Acetaldehyde<0.02,
Impact Test at -40℃	No cracks and break
Routine Temperature at 110℃	No cracks and break

	ENVIRONMENTAL PROTECTION
	Reach SVHC 255	PASS DMF FREE PASS
	CA65	PASS Odorless PASS
	EN71-3	PASS LOW VOCS PASS
	PAHS Free	PASS PVC/PU FREE PASS
	Phthalate Free	PASS

Application

Apply to automotive interior, health-care furnishing, commercial projects

Color Fastness
High Strength Physical Property
Eco-friendly
Weathering Resistance
Flame Resistance
Antibacterial Mouldproof
QUV test

Certificate

Laboratory

Caiwing has a complete team and management system in quality control. All testing operations are carried out in strict accordance with ISO, ASTM, AATCC, SATRA, DIN, GB. In depth cooperation with major testing institutions (SGS, Intertek, etc.) and industry standard setting institutions, real-time learning and updating of self technology, to provide customers with the latest testing standards.

Production Workshop

Caiwing selects the global high-quality supply system to provide diversified products and services for customers in needs.
It has a complete testing center and application analysis team, which can develop and provide solutions for stamoid marine vinyl fabric according to the needs of different scenarios.

Shipping

How To Package

The thick paper tube avoid damage the leather in long-term transportation and reduce the tail wrinkles of the leather.
Generally, the diameter is 4cm, and more diameters can be selected, such as 5cm, 6cm, etc.

Special Packing Can Be Negotiated

Inner Packing

Plastic film is used for inner packing to keep leather clean.

Outer Packaging

In order to better protect the leather, the outer packaging uses woven bags.

Shipping Mark

Each batch of products will paste the shipping mark according to the information provided by customers.

How To Clean

CARE + MAINTENANCE GUIDE

Do not store in long-term wet places. This will accelerate the aging of the leather.
It can not be placed in direct sunlight for a long time.
If any stain is found, please clean it in time. The longer the time, the more difficult it is to clean the stain.
Do not soak the leather.

STAIN AND DISINFECTIENT RECOMMENDATIONS

Recommended Cleaning Solution: Mixture of Tide® or Oxiclean®
and warm water (1 teaspoon of soap for every 16 ounces water)

*For general spills, such as water, coffee, wine, sauce,milk etc.:

Wipe off the spills with napkin, and then use a clean cloth moistened with water to wipe in lines until it is clean, it is important to wipe the surface with a dry cloth or napkin to remove any remaining moisture.

If the spill has evolved into a stain, a mixture of a mild soap, and

water (See recommendation above) should be used to remove the stain. Dampen a cloth with the mixture and gently work the stain in

a circular motion. Avoid rubbing the infected area aggressively, and be sure not to over saturate the fabric. After the stain is removed, dampen a cloth with water only and wipe away any excess soap left behind, and wipe the surface with a dry cloth to remove any remaining moisture.
*For tougher, non-liquid spills, such as mustard, mayonnaise, sunscreen, etc.

Wipe off the spills with napkin, and then use a clean cloth moistened with water to wipe in lines until it is clean, it is important to wipe the surface with a dry cloth or napkin to remove any remaining moisture.

If the spill has evolved into a stain, a mixture of a mild soap, and

water (See recommendation above) should be used to remove the stain. Dampen a cloth with the mixture and gently work the stain in

a circular motion. Avoid rubbing the infected area aggressively, and be sure not to over saturate the fabric. After the stain is removed, dampen a cloth with water only and wipe away any excess soap left behind, and wipe the surface with a dry cloth to remove any remaining moisture.
*For Healthcare stains, such as Blood, Urine, Disinfectant, etc.:

Wipe off the spills with napkin, and then use a clean cloth moistened with water to wipe in lines until it is clean, it is important to wipe the surface with a dry cloth or napkin to remove any remaining moisture.

If the spill has evolved into a stain, a mixture of a mild soap, and

water (See recommendation above) should be used to remove the stain. Dampen a cloth with the mixture and gently work the stain in

a circular motion. Avoid rubbing the infected area aggressively, and be sure not to over saturate the fabric. After the stain is removed, dampen a cloth with water only and wipe away any excess soap left behind, and wipe the surface with a dry cloth to remove any remaining moisture.
*STAIN AND DISINFECTIENT RECOMMENDATIONS CONTINUED

Wipe off the spills with napkin, and then use a clean cloth moistened with water to wipe in lines until it is clean, it is important to wipe the surface with a dry cloth or napkin to remove any remaining moisture.

If the spill has evolved into a stain, a mixture of a mild soap, and

water (See recommendation above) should be used to remove the stain. Dampen a cloth with the mixture and gently work the stain in

a circular motion. Avoid rubbing the infected area aggressively, and be sure not to over saturate the fabric. After the stain is removed, dampen a cloth with water only and wipe away any excess soap left behind, and wipe the surface with a dry cloth to remove any remaining moisture.
